Tinned Copper Earth Tape

Print this page
All Products

High-conductivity soft-drawn flat copper tape made in accordance with BS EN 13601 (Previously BS1432-C101), supplied fully-tinned for use in areas of high soil contamination or where different metals (e.g. aluminium and copper) will be in contact with each other. Used within a variety of earthing (grounding) and lightning protection applications.

Our tinned copper earthing tape is annealed for ultimate ductility, all tape sizes have radiused edges and are available in a range of coil lengths, dependant upon the tape dimensions.

Add to quote
SKU: TT Categories: , , , , ,

High-conductivity annealed soft drawn, fully tinned flat copper tape.

Order Reference Product Name Length Width CSA Amperage Rating Thickness Volume Weight Qty Add to quote
TT 253
50m
25.0mm
75mm2
175A
3.0mm
670g
Add
TT 256
40m
25.0mm
150mm2
350A
6.0mm
1.33kg
Add
TT 385
30m
38.0mm
190mm2
440A
5.0mm
1.69kg
Add
TT 404
30m
160mm2
370A
4.0mm
1.42kg
Add
TT 506
20m
50.0mm
300mm2
700A
6.0mm
2.68kg
Add
Can’t find what you’re looking for? Contact ETS on +44 (0) 20 8405 6789
or email: sales@etscablecomponents.com

Due to manufacturer design changes, some of the selection charts and other technical information published may change at short notice.

For the most current product technical data sheets, please contact us on 00 44 (0)20 8405 6789 or via sales@etscablecomponents.com
